Image similar
NXP Semiconductors PCA9685PW,112 PMIC - LED driver Linear TSSOP 28 Surface-mount
Product type
PMIC - LED driver
Enclosure
TSSOP 28
Mounting type
Surface-mount
Type
PCA9685PW,112
Manufacturer
NXP Semiconductors
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 1.99 / piece)
€ 1.99
incl. VAT
14-day return policy included
Technical specifications
- Type
PCA9685PW,112
- Product type
PMIC - LED driver
- Enclosure
TSSOP 28
- Manufacturer
NXP Semiconductors
- Manuf. code
NXP
- Type (PMIC)
Linear
- Internal switch(es)
Yes
- Channels
16
- Input voltage (min.)
2.3 V
- Input voltage (max.)
5.5 V
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+85 °C
- Voltage output (num.)
5.5 V
- Dimming
PWM
- Frequency
1 MHz
- Power output/channel
25 mA
- Range of uses
Background lighting
- Mounting type
Surface-mount
Documents & Downloads
Datasheet
Datasheet 1116598 NXP Semiconductors PCA9685PW,112 PMIC - LED driver Linear TSSOP 28 Surface-mount
User & Safety Instructions
User & Safety Instructions 1116598 NXP Semiconductors PCA9685PW,112 PMIC - LED driver Linear TSSOP 28 Surface-mount
Description
Integrated circuits from leading manufacturers. Please read our extensive documentation which is free to download.
