Buy ODU S11M07-P02MPH0-0000 MEDI-SNAP Circular Connector With Push-pull Lock Nominal current (details): 14 A Pins: 2

A grey and turquoise electrical plug adapter with a lockable mechanism.

Exploded view diagram of a connector with labels: 'Clamping Nut', 'Clamping Collet', 'Contact Insert', 'Connector Housing'.

1/2

Product type

Bullet connector

Connector type

Plug, straight

Total no. of pins

Connection

Soldering

Content

1 pc(s)

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

57 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 8.39 / piece)

€ 8.39

plus VAT.

Report legal concerns

Highlights & Details

ODU S11M07-P02MPH0-0000 MEDI-SNAP Circular Connector With Push-pull Lock Nominal current (details): 14 A Pins: 2

Our service for you

Technical specifications

Fire protection class UL94 V0/4.5

Type: S11M07-P02MPH0-0000

Product type: Bullet connector

Connector type: Plug, straight

Total no. of pins: 2

Connection: Soldering

Factory colour: Grey

Content: 1 pc(s)

Nominal current: 14 A

Nominal current - rounded value: 14 A

Seal: Push-pull lock

Nominal voltage: 600 V

Contact material: Brass, nickel and gold plated

Case material: PSU (polysulphone)

: 20

Connection angle: 180°

Manufacturer part #: S11M07-P02MPH0-0000

Number of pins: 2

(Ø): 14 mm

max. cross section: 0.5 mm²

Cross-section range: 0.5 mm² (max)

RoHS-compliant: Yes

: IP50

Series: MEDI-SNAP®

Nominal voltage (details): 600 V

Nominal current (details): 14 A

Cross section: 0.5 mm²

Pins: 2

Connection: Solder

Temperature range: -50 to +120 °C

Documents & Downloads

Datasheet

Datasheet 748017 ODU S11M07-P02MPH0-0000 MEDI-SNAP Circular Connector With Push-pull Lock Nominal current (details): 14 A Pins: 2

Description

Connector consists of housing, contact insert, chuck and clamping nut. Coding using tongue and groove. Over 2000 mating cycles possible. The housing is 100% contact protected. Sterilisation (autoclaving) possible approx. 20 times. Very high chemical resistance and simple installation.
