Paulmann 97767 LED transformer Constant voltage 65 W 5.4 A 12 V AC dimmable, Approved for use on furniture 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 27.99 / piece)
€ 27.99
incl. VAT
14-day return policy included
Highlights & Details
Transformer Halo + LED 0 - 65 W 230/12 V/AC
- Constant voltage
- 12 V AC
- 5.4 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
- Dim
(L x W x H) 127 x 44 x 28 mm
- Factory colour
White
- Output voltage (max.)
12 V AC
- Output voltage (min.)
12 V AC
- Test mark
SGS-Zertifiziert
- Max. output current
5.4 A
- Output current (max.) - rounded
5.4 A
- Operating voltage
230 V AC
- Protection class
II
- LED driver features
dimmable
Approved for use on furniture
- Connection
Screw terminal
- Max. power
65 W
- No. of outputs
1 x
- Output current (min.)
5.4 A
- Input voltage (max.)
240 V AC
- Min. input voltage
220 V AC
- Weight
123 g
- Power (min.)
0 W
- Power range
0 up to 65 W
- Width
44 mm
- Height
28 mm
- Length
127 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1192245 Paulmann 97767 LED transformer Constant voltage 65 W 5.4 A 12 V AC dimmable, Approved for use on furniture 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1192245 Paulmann 97767 LED transformer Constant voltage 65 W 5.4 A 12 V AC dimmable, Approved for use on furniture 1 pc(s)
User & Safety Instructions 1192245 Paulmann 97767 LED transformer Constant voltage 65 W 5.4 A 12 V AC dimmable, Approved for use on furniture 1 pc(s)
Description
The universal problem solver for AC-supplied LED up to 40 watts and for halogen up to 65 watts.
·Integrated temperature monitor + electronic fuse
·Integrated soft start
·Integrated radio protection
·Increased spike protection
·Integrated overload protection
·Integrated fire protection
·MM characters
This text is machine translated.
·Integrated temperature monitor + electronic fuse
·Integrated soft start
·Integrated radio protection
·Increased spike protection
·Integrated overload protection
·Integrated fire protection
·MM characters
This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
