Building Technology & Smart LivingElectrical Wiring3-Phase Power SupplyCEE Connectors, CEE Adapters

PC Electric Power Twist 4232-6.u CEE add-on socket 32 A 3-pin 1 pc(s)

A grey, square industrial socket with a round cover partially concealing the interior of the socket.
EAN:
Part number:
Item no:
Available soon
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 28.99 / piece)
€ 28.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

  • Housing material PA6
  • 3 pins (2P+PE)
  • Clock position: 6h
  • Rated voltage / frequency 200-250V~ / 50+60Hz
  • Contacts: Brass
  • Connection technology: Screw terminals
  • Dimensions (flange/hole): 92x100 mm/77x85 mm
Product type

CEE add-on socket

Nominal current

32 A

Nominal current - rounded value

32 A

Type A

Screws

Type B

CEE connector

Cores

3

IP67

Standards

IEC 60309

Factory colour

Bronze green (matt)

Dim

(W x H) 92 mm x 100 mm

Width

92 mm

Height

100 mm

Content

1 pc(s)

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2937036 PC Electric Power Twist 4232-6.u CEE add-on socket 32 A 3-pin 1 pc(s)

Description

CEE-Add-on socket diagonal (92x100mm) 32A 3p 6h IP67 bronze green
