Name: Phoenix Contact ELR H3-I-PT- 24DC/500AC-2 Magnetic starter 24 V DC 2.4 A Compatible with (relay brand): Phoenix Contact
Brand: Phoenix Contact
SKU: 1573036
Availability: BackOrder

Electronic module in a green enclosure by Phoenix Contact, displaying a maximum current of 2.4 A, with orange connectors and LED indicator.

Image similar

Product type

Magnetic starter

No. of pins

3-pin

Nominal voltage

24 V DC

Current load

2.4 A

Connection

Pull spring

Datasheet (PDF)

Dispatches on Thu 22 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 134.99 / piece)

€ 134.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

"2-in-1" hybrid motor starter

Clockwise rotation /motor protection
Replaces 2 contactors

Technical specifications

Packaging type: Piece

Product type: Magnetic starter

Type: ELR H3-I-PT- 24DC/500AC-2

No. of pins: 3-pin

Nominal voltage: 24 V DC

Control voltage (min.): 19.2 V DC

Control voltage (max.): 30 V DC

Control voltage range: 19.2 - 30 V DC

Switching voltage (min.): 42 V AC

Switching voltage (max.): 550 V AC

Permanent current (max.): 2.4 A

Current load: 2.4 A

Compatible with: Phoenix Contact

Compatible with series: Phoenix Contact ELR H3 series

Connection: Pull spring

: IP20

Min. temperature: -25 °C

Max. temperature: +70 °C

Width: 99 mm

Height: 22.5 mm

Depth: 114.5 mm

Dim: (W x H x D) 99 x 22.5 x 114.5 mm

Content: 1 pc(s)

: 22.5

: 107.5 mm

: 114 mm

: 1

: 1

: 0.18-2.4 A

: TRUE

: 19.2-19.2 V

: IP20

: Spring clamp connection

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1573036 Phoenix Contact ELR H3-I-PT- 24DC/500AC-2 Magnetic starter 24 V DC 2.4 A Compatible with (relay brand): Phoenix Contact

User & Safety Instructions

User & Safety Instructions 1573036 Phoenix Contact ELR H3-I-PT- 24DC/500AC-2 Magnetic starter 24 V DC 2.4 A Compatible with (relay brand): Phoenix Contact

Description

The 3-phase hybrid motor starter with current monitoring combines two functions in one: legal protection and motor protection relay.

This text is machine translated.

Description

The 3-phase hybrid motor starter with current monitoring combines two functions in one: legal protection and motor protection relay.

This text is machine translated.
