Image similar
Phoenix Contact Pin housing cable MSTBHK Total number of pins 10 Contact spacing: 5 mm 1765085 50 pc(s)
EAN:
Part number:
Item no:
Product type
Pin housing cable
Connector type
Plug, mount
No. of rows
1
Series
MSTBHK
CS
5 mm
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 9.10 / piece)
€ 455.00
incl. VAT
14-day return policy included
Highlights & Details
Housing MSTBHK 2,5/10-G
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 10
Technical specifications
- Product type
Pin housing cable
- Connector type
Plug, mount
- No. of rows
1
- Connector system
wire-to-board
- Series
MSTBHK
- Features
+ TS35 mounting feet
- CS
5 mm
- Pins per row
10
- Total number of pins
10
- Width
52.30 mm
- Nominal current
12 A
- Nominal current - rounded value
12 A
- Content
50 pc(s)
- AWG max.
12
- AWG (min.)
24
- Stripping length (max.)
7.00 mm
- Dim
(L x W x H) 27.70 x 52.30 x 29.10 mm
- Connection
Screw terminal
Plug
- Manufacturer part #
1765085
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
320 V
- Height
29.10 mm
- Length
27.70 mm
- max. cross section
2.5 mm²
- Min. cross section
0.2 mm²
- Type
MSTBHK 2,5/10-G
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 569074 Phoenix Contact Pin housing cable MSTBHK Total number of pins 10 Contact spacing: 5 mm 1765085 50 pc(s)
User & Safety Instructions
User & Safety Instructions 569074 Phoenix Contact Pin housing cable MSTBHK Total number of pins 10 Contact spacing: 5 mm 1765085 50 pc(s)
Description
Plug component, Nominal current: 12 A, Rated voltage (III/2): 320 V, Number of positions: 10, Pitch: 5 mm, Connection method: Screw connection, Color: green, Contact surface: Tin, Assembly: DIN rail
