Name: Phoenix Contact Pin housing PCB MCV Total number of pins 3 Contact spacing: 3.81 mm 1712843 200 pc(s)
Brand: Phoenix Contact
SKU: 568948
Availability: InStock

'Multi-socket power strip with plastic casing' shows a rectangular, black power strip with multiple socket outlets arranged in a neat grid.

Image similar

Product type

Pin housing PCB

Connector type

Plug, horizontal mount

No. of rows

Series

MCV

3.81 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Wed 11 Nov

167 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 200 pc(s))

Set(s)

Total (€ 1.07 / piece)

€ 214.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Base strip MCV 1,5/ 3-G-3,81 P26 THRR32

Content: 200 pc(s)
No. of rows: 1
Total number of pins: 3

Technical specifications

Product type: Pin housing PCB

Connector type: Plug, horizontal mount

No. of rows: 1

Connector system: wire-to-board

Series: MCV

Features: for reflow
+ screw lock

CS: 3.81 mm

Pins per row: 3

Total number of pins: 3

Width: 12.82 mm

Nominal current: 8 A

Nominal current - rounded value: 8 A

Content: 200 pc(s)

Dim: (L x W x H) 7.25 x 12.82 x 11.80 mm

Connection: Print

Manufacturer part #: 1712843

Factory colour: Black

Industrial packaging: Yes

Contact material: Tin plated

Nominal voltage: 160 V

Height: 11.80 mm

Length: 7.25 mm

Connector orientation: Perpendicular (to the PCB)

Type: MCV 1,5/ 3-G-3,81 P26 THRR32

Documents & Downloads

Datasheet

Datasheet 568948 Phoenix Contact Pin housing PCB MCV Total number of pins 3 Contact spacing: 3.81 mm 1712843 200 pc(s)

User & Safety Instructions

User & Safety Instructions 568948 Phoenix Contact Pin housing PCB MCV Total number of pins 3 Contact spacing: 3.81 mm 1712843 200 pc(s)

Description

Header, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 3, Pitch: 3.81 mm, Color: Black, Contact surface: Tin, Assembly: Taped SMD/THT/THR components, User information and design recommendations for through hole reflow technology can be found under ¿Downloads¿
