Phoenix Contact Socket housing cable GMSTB Total number of pins 8 Contact spacing: 7.50 mm 1766945 50 pc(s)
EAN:
Part number:
Item no:
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
Series
GMSTB
CS
7.50 mm
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 6.90 / piece)
€ 345.00
incl. VAT
14-day return policy included
Highlights & Details
Printed-circuit board connector GMSTB 2,5/ 8-ST
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 8
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
GMSTB
- Features
+ extractor sleeve
- CS
7.50 mm
- Pins per row
8
- Total number of pins
8
- Width
58.00 mm
- Nominal current
12 A
- Nominal current - rounded value
12 A
- Content
50 pc(s)
- AWG max.
12
- AWG (min.)
24
- Stripping length (max.)
7.00 mm
- Dim
(L x W x H) 15.00 x 58.00 x 18.20 mm
- Connection
Screw terminal
Plug
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1766945
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
630 V
- Height
18.20 mm
- Length
15.00 mm
- max. cross section
2.5 mm²
- Min. cross section
0.2 mm²
- Type
GMSTB 2,5/ 8-ST
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 569258 Phoenix Contact Socket housing cable GMSTB Total number of pins 8 Contact spacing: 7.50 mm 1766945 50 pc(s)
User & Safety Instructions
User & Safety Instructions 569258 Phoenix Contact Socket housing cable GMSTB Total number of pins 8 Contact spacing: 7.50 mm 1766945 50 pc(s)
Description
Plug component, Nominal current: 12 A, Rated voltage (III/2): 630 V, Number of positions: 8, Pitch: 7.5 mm, Connection method: Screw connection, Color: green, Contact surface: Tin
