Rittal 7030022 Signal processing module DK 7030.022 1 pc(s)
EAN:
Part number:
Item no:
Product type
Signal processing module
Type
DK 7030.022
Connector
RJ12
Clip
RJ45
Features
LED indicator
Factory colour
Grey (RAL 7035)
Black (RAL 9005)
Number
Total (€ 1,083.19 / piece)
€ 1,083.19
plus VAT.
14-day return policy included
DK CMC III PU 19" EDITION
Technical specifications
- Material: plastic
- Aluminium profile, anodized black
- Net weight: 2.2 kg
- Gross weight: 2.452 kg
- Surface: Front: Smooth
- Housing: Structure
- Dimensions: Width 450 mm
- Height: 44 mm
- Depth: 144 mm
- Benefit: High availability through redundant power supply.
- Cost optimization through optimized space utilization and connection technology.
- Colour: Housing: RAL 7035
- Front panel RAL 9005
- Piezo signal transmitter for acoustic information
- Time function by real-time clock with NTP
- Areas of application: Monitoring of cabinets in IT, industry and building technology.
- Operating temperature range -0°C...45°C.
- How it works: Central Monitoring Unit for the CMC III system.
- Direct connection of the device via SNMP over Ethernet
- Collects measurement data and alarms network management systems or control states when exceeding freely adjustable limit values.
- Humidity (non-condensing): 5...95 %
- Interfaces bus system: RJ45 CAN bus
- Alarm relay output: Terminal up to 1.5 mm² (max. 24 V DC/1 A)
- Mobile Website: For Android and Windows Phone
- Network interface: Ethernet according to IEEE 802.3 via 10/100BaseT full-duplex 10/100 Mbit/s, PoE
- UPS interface: PoE (Power over Ethernet)
- Serial interface RJ12
- Streaming interface: AXIS network camera with VAPIX® version 3
- Number of sensors (max.): 16
- LED indicators (back panel): Network status
- LED indicators (front): Status
- TCP/IPv4 protocol
- TCP/IPv6
- SNMPv1
- SNMPv2c
- SNMPv3
- Telnet
- SSH
- FTP
- SFTP with SSL
- HTTP
- HTTPS with SSL
- NTP
- DHCP
- DNS
- SMTP
- Syslog
- LDAP
- Radius
- OPC UA
- ModBUS/TCP
- RS-232
- Product type
Signal processing module
- Type
DK 7030.022
- Connector
RJ12
Clip
RJ45
- Features
LED indicator
- Factory colour
Grey (RAL 7035)
Black (RAL 9005)
- Content
1 pc(s)
- Length
144 mm
- Width
450 mm
- Height
44 mm
- Weight
2.2 kg
- Material
Plastic
Aluminium rail
- Material properties
anodised
- Max. media temperature
+45 °C
- Media temperature (min.)
0 °C
Communication module
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3386757 Rittal 7030022 Signal processing module DK 7030.022 1 pc(s)
Description
CMC III processor module 19" edition
The CMC III Processing Unit 19" Edition is the central unit of the CMC III monitoring system. Up to 16 external sensors / CAN bus connection units can be connected. The unit can be connected to the data network via Ethernet, configured via Web / USB, send alarms via an e-mail server and connected to the network management system of a company with SNMP.
This text is machine translated.
The CMC III Processing Unit 19" Edition is the central unit of the CMC III monitoring system. Up to 16 external sensors / CAN bus connection units can be connected. The unit can be connected to the data network via Ethernet, configured via Web / USB, send alarms via an e-mail server and connected to the network management system of a company with SNMP.
