Name: Rittal CX 6702.000 Desk casing (bottom ) (W x H x D) 1200 x 675 x 400 mm Steel plate Grey (RAL 7035) 1 pc(s)
Brand: Rittal
SKU: 3389191

Grey metal cabinet with two doors and a small red handle in the centre.

Product type

Desk casing (bottom )

Material

Steel plate

IP rating

IP55

Width

1200 mm

Height

675 mm

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Material: Housing: Steel sheet 1.5 mm
Door: Steel sheet, 2.0 mm, circulating foamed PU-sealing
Mounting plate: Steel sheet, 2.5 mm
Gross weight: 57.125 kg
Surface: Housing and door: Dip-primed, externally powder coated, textured finish
Galvanised mounting plate
Dimensions: Width 1,200 mm
Height: 675 mm
Depth: 400 mm
Colour RAL 7035
Mounting plate dimensions (W x H) 1,120 x 625 mm
IK code: IK10
Number of doors: 2
Base material: Steel sheet
Design: Lower part
Door opening angle 130°
Shutter: Design shutter: 3-point-closure system
Number of closures: 1
Locking insert: 3 mm double bit
Number of closures: 1
Design closure: 3-point-locking system
Locking insert: 3 mm double bit
Protection class IP according to IEC 60 529:IP 55

Product type: Desk casing (bottom )

Features: Double sided ward

Material: Steel plate

: IP55

Factory colour: Grey (RAL 7035)

Type: 2 door

Front panel size: (W x H) 1120 mm x 625 mm

Width: 1200 mm

Height: 675 mm

Content: 1 pc(s)

Dim: (W x H x D) 1200 x 675 x 400 mm

Depth: 400 mm

Type: CX 6702.000

: Grey

: 1200 mm

: 675 mm

: 400 mm

: 7035

: 2

: Steel

: IP55

: Powder coating

: Base unit

: 12

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3389191 Rittal CX 6702.000 Desk casing (bottom ) (W x H x D) 1200 x 675 x 400 mm Steel plate Grey (RAL 7035) 1 pc(s)

Description

CX desk system, desk lower section, BHT: 1200x675x400 mm, sheet steel

CX desk bases, four widths and two different depths as the basis for each console solution. The AX lock plate guarantees a uniform appearance; the two-part base plates are included in the delivery for a simple cable routing.
