Sauter TN 60-0.01EE Thickness gauge 3 - 60 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 1,649.00 / piece)
€ 1,649.00
incl. VAT
Only 6 Piece(s) available
Highlights & Details
Ultrasonic Material thickness meter TN60-05101 01 EE
- Two measurement modes for the determination of the material thickness:
- Pulse echo mode
- Echo Echo Mode
- Data Interface RS-232, standard
- Internal data storage for up to 20 files (with up to 100 individual values per file)
Technical specifications
- Readability: 0.01 mm
- Measuring frequency: 5 MHz
- USB.
- Product type
Thickness gauge
- Measuring type
Aluminium
Grey iron
Cast iron
Copper
Brass
Polyethylene
PVC
Fused quartz
Steel
Zinc
- Reading range
3 - 60 mm
Manufacturer's standards (no certificate)
- Operating voltage
2 x 1.5 V AA batteries (AA)
- Dim
(L x W x H) 150 x 32 x 74 mm
- Weight
250 g
- Display
LCD
- Resolution
0.01 mm
- Accuracy
0.01 mm
- Content
1 pc(s)
- Reading range (max.)
60 mm
- Reading range (min.)
3 mm
- Measuring type
Ultrasound
- Width
32 mm
- Height
74 mm
- Length
150 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1676542 Sauter TN 60-0.01EE Thickness gauge 3 - 60 mm
User & Safety Instructions
User & Safety Instructions 1676542 Sauter TN 60-0.01EE Thickness gauge 3 - 60 mm
Information
Information 1676542 Sauter TN 60-0.01EE Thickness gauge 3 - 60 mm
Description
Echo Echo measurements lead to a determination of the actual material thickness regardless of any existing coating. Thus, the wall thickness, for example, pipes non-destructive, i.e. without removal of the coating, can be determined.
Echo Echo measurements are only possible with the included measuring head (ATU-US 12)
This text is machine translated.
Echo Echo measurements are only possible with the included measuring head (ATU-US 12)
This text is machine translated.
Features
- External measurement head
- Supplied in a robust carrying case
- Scan mode (10 measurements per second) or individual measuring point can be selected.
- Selectable units: mm, inch
Scope of delivery
- Batteries
- Measuring head
- Carrying case
- Contact Gel
