Name: Schneider Electric A9L1F625 A9L1F625 Lightning conductor 1 pc(s)
Brand: Schneider Electric
SKU: 3343737
Availability: InStock

Schneider Electric A9L1F625 A9L1F625 Lightning conductor 1 pc(s)-0

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Mon 2 Nov

17 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 1,579.00 / piece)

€ 1,579.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Product type: Lightning conductor

Manufacturer part #: A9L1F625

Dim: (W x H x D) 126 x 105 x 86 mm

Width: 126 mm

Height: 105 mm

Depth: 86 mm

Content: 1 pc(s)

: DIN rail (top hat rail) 35 mm

: 25 kA

: 4

: 7 modular spacing

: 1.5 kV

: TRUE

: 75 kA

: 275 V

: 240 V

: Type 1 + 2

: 1.5 kV

: Optic

: IP20

: 1.5 kV

: TRUE

: 35 mm²

: 25 mm²

: 156.2 kJ/Ohm

: TRUE

: FALSE

: FALSE

: FALSE

: FALSE

: TRUE

: TRUE

: FALSE

: FALSE

: FALSE

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 3343737 Schneider Electric A9L1F625 A9L1F625 Lightning conductor 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3343737 Schneider Electric A9L1F625 A9L1F625 Lightning conductor 1 pc(s)

Information

Repairability/durability data sheet 3343737 Schneider Electric A9L1F625 A9L1F625 Lightning conductor 1 pc(s)

Conformity certificate

Conformity certificate 3343737 Schneider Electric A9L1F625 A9L1F625 Lightning conductor 1 pc(s)

Description

Acti9 iPRD1 F25r modular combination conductor for use in lightning protection class I+II. Integrated fuse in the device, no earth leakage circuit breaker necessary (safety-proof). Telecommunication contact. Optical function/defect display of arrester and integrated fuse (green OK/ red device defective). Suitable for TN-S and TT networks. U0 nominal voltage 240 V AC (50 Hz). UC maximum continuous voltage 305V AC (N-PE) / 255V AC (L-N). In-nominal leakage surge current 25/100 kA (L-N)/(N-PE). Imax maximum leakage surge current 65/150 kA (L-N)/(N-PE). IIMP 25/100kA (L-N/N-PE). Up protection level 1.5 kV (L-N/N-PE). DIN-Rail mount Dimensions (W) 126mm x (H) 105mm x (D) 86mm. Weight 1,187kg Protection class IP20 integrated. Operating temperature: -40 to +85 oC. COMPLIES WITH IEC 61643-11:2011, EN 61643-11:2012+A11:2018.
