Name: Schneider Electric CAE22Q5 Electrical contactor w/o display Piece 1 pc(s)
Brand: Schneider Electric
SKU: 3754720
Availability: BackOrder

Schneider Electric Easy TeSys Control CAE22 contactor relay with orange manual test buttons and labeled terminals 13 NO, 21 NC, 31 NC, 43 NO.<br>

Product type

Electrical contactor

Connection

Screw terminal

Packaging type

Piece

Type

CAE22Q5

Control voltage (min.)

380 V AC

Datasheet (PDF)

Dispatches on Wed 4 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 49.99 / piece)

€ 49.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Auxiliary circuit connection type: Screw terminals
Number of auxiliary contacts as NO contacts: 2
Number of auxiliary contacts as NO contacts, leading: 0
Number of auxiliary contacts as changer: 0
Number of auxiliary contacts as NC contacts: 2
Number of auxiliary contacts as NC contacts, delayed switching: 0
Rated operating current Ie, 400 V 10 A
Rated switching current 0,005 A
Rated control supply voltage AC 50 Hz: 380-380 V
Operating voltage AC 50 Hz: 690-690 V
Operating voltage AC 60 Hz: 690-690 V
Suitable for manual operation: No.
With LED indicator: No.
DIN rail/screw mounting
Interface: No.
Operating voltage type: AC
Type of voltage for activation: AC

Packaging type: Piece

Product type: Electrical contactor

Type: CAE22Q5

Control voltage (min.): 380 V AC

Control voltage (max.): 380 V AC

Control voltage range: 380 - 380 V AC

Switching voltage (max.): 690 V AC

Permanent current (max.): 10 A

Features: w/o display

Connection: Screw terminal

Width: 45 mm

Height: 74 mm

Depth: 80 mm

Dim: (W x H x D) 45 x 74 x 80 mm

Content: 1 pc(s)

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 3754720 Schneider Electric CAE22Q5 Electrical contactor w/o display Piece 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3754720 Schneider Electric CAE22Q5 Electrical contactor w/o display Piece 1 pc(s)

Description

Easy TeSys control relay for use categories AC-15/AC-14 to 10A/690V. It offers 4 undelayed contacts (2NO+2NC), a 380V 50Hz AC coil, connections via screw terminals. For demanding applications with standard operating speeds up to 3 cycles/second, it offers standard reliability and durability. Compact (45mm width), for clipping onto 35mm DIN-rails or mounting. Multi-standard certified (IEC, CCC, EAC) and RoHS/REACH compliance.
