Schneider Electric NSYKDB9U4F 19 inch Wall cabinet 9 U Grey
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 209.99 / piece)
€ 209.99
incl. VAT
14-day return policy included
Technical specifications
- Number of doors: 1
- Type of ventilation: Without
- Design of the surface: Powder-coated
- Profile rail design: Without
- Max. load 50 kg
- With attic: Yes
- With earthing: No.
- With front door: Yes
- With side walls: Yes
- Mounting level: Front
- RAL number: 7035
- Grid pitch 482.6 mm (19 inches)
- Protection class (NEMA): 1
- Dismantling: Yes
- Product type
Wall cabinet
- Suitable for server rack cabinet (inch)
19 inch
- Rack unit
9 U
- Dim
(W x H x D) 600 x 485 x 400 mm
- Material
Steel
- Content
1 pc(s)
- Factory colour
Grey
- Width
600 mm
- Height
485 mm
- Depth
400 mm
IP20
- Type
With fixed frame
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3755469 Schneider Electric NSYKDB9U4F 19 inch Wall cabinet 9 U Grey
User & Safety Instructions
User & Safety Instructions 3755469 Schneider Electric NSYKDB9U4F 19 inch Wall cabinet 9 U Grey
Description
This Actassi case is a wall-mounted, flat-packed product that comes in a single package. It consists of welded steel plate, is powder coated, has a leather structure and is painted with RAL 7035 light gray epoxy polyester. The housing consists of a body, a pair of 19-inch fixed stands and a transparent door made of security glass with key No. 333. The dimensions of this space-saving housing are 485 mm in height (or 9 U), 600 mm in width and 400 mm in depth.
This text is machine translated.
This text is machine translated.
