Metal enclosure by Schneider Electric with four round openings on the front, suitable for housing push buttons or switches.

Metal enclosure by Schneider Electric with four round openings on the front, suitable for housing push buttons or switches.

Schneider Electric

Datasheet (PDF)

Dispatches on Tue 27 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 109.99 / piece)

€ 109.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Packaging type: Piece

Product type: Housing

Material: Metal

Recess diameter: 22 mm

Width: 80 mm

Height: 175 mm

(Ø): 22 mm

Dim: (Ø x H) 22 mm x 175 mm

: IP65

Min. temperature: -25 °C

Max. temperature: 70 °C

Content: 1 pc(s)

Type: XAPD3504

Depth: 77 mm

Weight: 1.0160 kg

: 80

: 175 mm

: 77 mm

: 22.5 mm

: 4

: Grey

: Zinc

: Surface mounting housing

: IP65/IP67

: Other

: Other

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2922261 Schneider Electric XAPD3504 XAPD3504 Housing (Ø x H) 22 mm x 175 mm 1 pc(s) Piece

Datasheet 2922261 Schneider Electric XAPD3504 XAPD3504 Housing (Ø x H) 22 mm x 175 mm 1 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 2922261 Schneider Electric XAPD3504 XAPD3504 Housing (Ø x H) 22 mm x 175 mm 1 pc(s) Piece

User & Safety Instructions 2922261 Schneider Electric XAPD3504 XAPD3504 Housing (Ø x H) 22 mm x 175 mm 1 pc(s) Piece

Information

Information 2922261 Schneider Electric XAPD3504 XAPD3504 Housing (Ø x H) 22 mm x 175 mm 1 pc(s) Piece

Information 2922261 Schneider Electric XAPD3504 XAPD3504 Housing (Ø x H) 22 mm x 175 mm 1 pc(s) Piece

Information 2922261 Schneider Electric XAPD3504 XAPD3504 Housing (Ø x H) 22 mm x 175 mm 1 pc(s) Piece

Description

Empty housing of the Harmony XAP series. Made of metal with zinc alloy. Colour: Grey, with a hole of 4 x 22 mm. Size of housing: 80x175x77. With a M25 cable gland. IP protection classes up to IP69K and ambient temperatures from -25°C to +70°C. The modular Harmony series of push switches with 22mm or 30mm mounting dimensions combine easy installation, efficiency, modern design, flexibility with highest ruggedness. Product standards according to EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 NO 14, UL 508, EN/IEC 60947-1, JIS C 4520. Certifications according to DNV, GL, UL listed, RINA, BV, CSA, LROS (Lloyds Register of Shipping). Product standards according to EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 NO 14, UL 508, EN/IEC 60947-1, JIS C 4520.

This text is machine translated.

Description

Empty housing of the Harmony XAP series. Made of metal with zinc alloy. Colour: Grey, with a hole of 4 x 22 mm. Size of housing: 80x175x77. With a M25 cable gland. IP protection classes up to IP69K and ambient temperatures from -25°C to +70°C. The modular Harmony series of push switches with 22mm or 30mm mounting dimensions combine easy installation, efficiency, modern design, flexibility with highest ruggedness. Product standards according to EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 NO 14, UL 508, EN/IEC 60947-1, JIS C 4520. Certifications according to DNV, GL, UL listed, RINA, BV, CSA, LROS (Lloyds Register of Shipping). Product standards according to EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 NO 14, UL 508, EN/IEC 60947-1, JIS C 4520.

This text is machine translated.
