Shelly Shelly Qubino Wave i4 Automation routine memory Z-Wave
EAN:
Part number:
Item no:
Highlights & Details
Shelly scene activator 12 actions Z-Wave
- 868.4 MHz (CEPT countries) Z wave frequency band
- Manually activate or deactivate each scene created
- Execute synchronized actions or complex trigger scenarios
Technical specifications
- Number of inputs: 4
- Indoor range: Up to 40 m.
- CPU Z-WAVE™ S800
- Product type
Automation routine memory
Alexa
Google Home
- Transfer Standard (Smart Home)
Z-Wave
- Used at
Indoors
- Power supply (LOV)
mains-powered
- Operating voltage
100 V
240 V
- Data transfer (Smart Home)
Wireless
- Frequency
868.4 MHz
- Mounting type
Flush mount
- Factory colour
Orange
- Width
42 mm
- Height
37 mm
- Depth
16 mm
- Weight
17 g
n.rel.
- Dim
(W x H x D) 42 x 37 x 16 mm
- Hub
Not required
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3066258 Shelly Shelly Qubino Wave i4 Automation routine memory Z-Wave
Description
The device is a module with 4 digital inputs (110 - 240 V AC), which controls other devices within the Z-Wave network. It enables the manual activation or deactivation of scenes with a switch/button.
The device can be retrofitted into a standard flush-mounted socket, behind switches or in other places with less space.
This text is machine translated.
The device can be retrofitted into a standard flush-mounted socket, behind switches or in other places with less space.
This text is machine translated.
System requirements
- Z-wave, iOS, Android, HUAWEI, MQTT
