SIKU 100 LDTL Wall and ceiling fan 230 V 88 m³/h 10 cm
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 69.99 / piece)
€ 69.99
incl. VAT
Only 10 Piece(s) available
Highlights & Details
Small blower 100 LD white delayed shut-off relay
- With ball bearings.
- 30 mm Installation height including front sheet
- With delayed shut-off relay
Technical specifications
- Building height 30 mm
- Product type
Wall and ceiling fan
- Nominal voltage
230 V
14 W
- Rotational speed
2300 U/min
- Air flow rate
88 m³/h
- Suitable for pipe Ø
10 cm
- Ventilation features
With time-delay relay
- Noise emission (max.)
33 dB
- Factory colour
White
- Dim
(W x H x D) 15 x 15 x 12.6 cm
- Width
15 cm
- Height
15 cm
- Depth
12.6 cm
- Type
Delayed shut-off relay:
- Rotational speed
2300 U/min
- Output (max.) (details)
88 m³/h
- Max. noise generation
33 dBa
- Max. power consumption
14 W
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 560184 SIKU 100 LDTL Wall and ceiling fan 230 V 88 m³/h 10 cm
User & Safety Instructions
User & Safety Instructions 560184 SIKU 100 LDTL Wall and ceiling fan 230 V 88 m³/h 10 cm
Warranty Terms
Warranty Terms 560184 SIKU 100 LDTL Wall and ceiling fan 230 V 88 m³/h 10 cm
Description
Blower with ball bearing and with closed Front sheet for Ventilation in small and middle rooms, e.g. kitchen,toilet or bathrooms. Suitable for wall and ceilings mounting The fan is designed with a delayed relay, which is set at 2-30 mins.
Scope of delivery
- Wall and Ceiling Fans · User manual.
- This text is machine translated.
