Buy Stäubli 61.7556-10025 Strand SILI-E 1 x 2.50 mm² Green Sold per metre | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

A red, thin electrical cable with exposed wire end on the right.

A red, thin electrical cable with exposed wire end on the right.

Image similar

Stäubli

Product type

Strand

No. of leads

1 x

Cross section (each core)

2.50 mm²

Cable type

SILI-E

Outside Ø

3.90 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

4 meter (Only while stocks last)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

meter

Total (€ 7.49 / piece)

€ 7.49

incl. VAT

Your Right to Cancel does not cover goods sold by the metre.

Only 4 meter available

14-day return policy included

Report legal concerns

Highlights & Details

Stäubli 61.7556-10025 Strand SILI-E 1 x 2.50 mm² Green Sold per metre

Technical specifications

Product type: Strand

No. of leads: 1 x

Content: Sold per metre

Cross section (each core): 2.50 mm²

Insulation material: Silicone

Cable features: Halogen-free
Flexible

Cable type: SILI-E

Outside Ø: 3.90 mm

Nominal voltage: 600 V

Packaged: No

Halogen-free: Yes

Manufacturer part #: 61.7556-10025

Factory colour: Green

Insulation: Silicone

Core layout: 651 x 0.07 mm

Max. length sold by the metre: 100 m

Sold per metre: Yes

Nominal voltage U0: 300 V

Test voltage: 2500 V AC

Cross section: 1 x 2.50 mm²

Max. temperature range (fixed installation): +150 °C

Min. temperature range (fixed installation): -50 °C

Type: SILI-E

Temperature range: -50 - +90 °C

Documents & Downloads

Datasheet

Datasheet 606505 Stäubli 61.7556-10025 Strand SILI-E 1 x 2.50 mm² Green Sold per metre

User & Safety Instructions

User & Safety Instructions 606505 Stäubli 61.7556-10025 Strand SILI-E 1 x 2.50 mm² Green Sold per metre

Description

Ultra flexible, basic insulated stranded wire. Oxygen-rich copper wire. Silicone-insulated wires are used in a wider temperature range than comparable TPE insulated wires. The material is also characterised by good ageing resistance, high impact strength, elongation at break and tear resistance. Examples of use: Internal wiring of moving components and modules under high thermal stress. Highly flexible connecting cables for working with low voltages in the laboratory.

Description

Ultra flexible, basic insulated stranded wire. Oxygen-rich copper wire. Silicone-insulated wires are used in a wider temperature range than comparable TPE insulated wires. The material is also characterised by good ageing resistance, high impact strength, elongation at break and tear resistance. Examples of use: Internal wiring of moving components and modules under high thermal stress. Highly flexible connecting cables for working with low voltages in the laboratory.
