TracoPower TDR 2-4813SM DC/DC converter (SMD) 48 V DC 15 V DC 134 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 24.99 / piece)
€ 24.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TDR 2-4813SM
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
134 mA
- Output current (max.) - rounded
134 mA
- Efficiency (max.)
83 %
2 W
- Insulation voltage
1600 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 13.55 x 12.5 x 18.9 mm
- Height
18.9 mm
- Length
13.55 mm
- Width
12.5 mm
- Output voltage (max.)
15 V DC
- Output voltage (min.)
15 V DC
- Weight
4.5 g
- Content
1 pc(s)
- Type
TDR 2-4813SM
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1509421 TracoPower TDR 2-4813SM DC/DC converter (SMD) 48 V DC 15 V DC 134 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1509421 TracoPower TDR 2-4813SM DC/DC converter (SMD) 48 V DC 15 V DC 134 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1509421 TracoPower TDR 2-4813SM DC/DC converter (SMD) 48 V DC 15 V DC 134 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact 2 W converter in SMD casing, input/output insulation 1600 V/DC, regulated outputs, 2:1 input range, short-circuit proof.
This text is machine translated.
This text is machine translated.
