TracoPower TEC 2-1222 DC/DC converter (print) 12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 11.76
30
6% = € 0.65
€ 11.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 11.76 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEC 2-1222
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Max. output current
83 mA
- Output current (max.) - rounded
83 mA
- Efficiency (max.)
84 %
2 W
- Insulation voltage
1600 V DC
- Enclosure
SIL 8
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+95 °C
- Dim
(L x W x H) 9.1 x 21.8 x 15.3 mm
- Height
15.3 mm
- Length
9.1 mm
- Width
21.8 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
-12 V DC
- Weight
4.5 g
- Content
1 pc(s)
