TracoPower TEL 10-1213 DC/DC converter (print) 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 10
Total (€ 26.99 / piece)
€ 26.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEL 10-1213
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Max. output current
666 mA
- Output current (max.) - rounded
666 mA
- Efficiency (max.)
87 %
10 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
88 °C
- Dim
(L x W x H) 23.80 x 13.70 x 8 mm
- Height
8 mm
- Length
23.80 mm
- Width
13.70 mm
- RoHS-compliant
Yes
- Output voltage (max.)
15.0 V DC
- Output voltage (min.)
15.0 V DC
- Weight
6.50 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372404 TracoPower TEL 10-1213 DC/DC converter (print) 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3372404 TracoPower TEL 10-1213 DC/DC converter (print) 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372404 TracoPower TEL 10-1213 DC/DC converter (print) 666 mA 10 W No. of outputs: 1 x Content 1 pc(s)
