TracoPower TEL 10-1222 DC/DC converter (print) 416 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 26.04
30
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 26.04 / piece)
€
Technical specifications
- Type
TEL 10-1222
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Max. output current
416 mA
- Output current (max.) - rounded
416 mA
- Efficiency (max.)
86 %
10 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
88 °C
- Dim
(L x W x H) 23.80 x 13.70 x 8 mm
- Height
8 mm
- Length
23.80 mm
- Width
13.70 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
6.50 g
- Product type
DC/DC converter (print)
