TracoPower TEL 10-4810 DC/DC converter (print) 2.7 A 10 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 27.72
30
4% = € 1.21
€ 26.51
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 27.72 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEL 10-4810
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Max. output current
2.7 A
- Output current (max.) - rounded
2.7 A
- Efficiency (max.)
80 %
10 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
88 °C
- Dim
(L x W x H) 23.80 x 13.70 x 8 mm
- Height
8 mm
- Length
23.80 mm
- Width
13.70 mm
- RoHS-compliant
Yes
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
6.50 g
- Content
1 pc(s)
