TracoPower TEL 12-2412 DC/DC converter 12 V DC 1 A 12 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 30.99 / piece)
€ 309.90
incl. VAT
Only 8 Piece(s) available
Highlights & Details
DC DC Converters
- Output 12 V DC / 1 A
- Power 12 W
- Solder pins
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
36.0 V DC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Min. input voltage
18.0 V DC
- Dim
(L x W x H) 23.8 x 13.7 x 14.0 mm
- Output voltage (max.)
12 V DC
- Connection
Solder pins
12 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
88 °C
- Operating temperature (min.)
-40 °C
- Weight
8.6 g
- Width
13.7 mm
- Height
14.0 mm
- Length
23.8 mm
- Type
TEL 12-2412
