TracoPower TEQ 20-7211WIR DC/DC converter 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 174.99 / piece)
€ 205.00
-15 %
€ 174.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter
- Type
TEQ 20WIR
- Min. input voltage
43 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
1 x
- Max. output current
4 A
- Output current (max.) - rounded
4 A
- Efficiency (max.)
86 %
20 W
- Insulation voltage
2250 V DC
- Connection
Spring-loaded connector
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
93 °C
- Dim
(L x W x H) 103 x 57.20 x 26.10 mm
- Height
26.10 mm
- Length
103 mm
- Width
57.20 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5.0 V DC
- Output voltage (min.)
5.0 V DC
- Weight
122 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2195731 TracoPower TEQ 20-7211WIR DC/DC converter 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 2195731 TracoPower TEQ 20-7211WIR DC/DC converter 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
