TracoPower THM 30-1215 DC/DC converter (print) 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 82.34 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THM 30-1215
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Efficiency (max.)
89 %
30 W
- Insulation voltage
5000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 50.80 x 25.40 x 10.20 mm
- Height
10.20 mm
- Length
50.80 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
24.0 V DC
- Output voltage (min.)
24.0 V DC
- Weight
32 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372039 TracoPower THM 30-1215 DC/DC converter (print) 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3372039 TracoPower THM 30-1215 DC/DC converter (print) 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372039 TracoPower THM 30-1215 DC/DC converter (print) 1.25 A 30 W No. of outputs: 1 x Content 1 pc(s)
