TracoPower TMG 30124 AC/DC PSU (print) 24 V DC 1.25 A 30 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 71.99 / piece)
€ 719.90
incl. VAT
14-day return policy included
Highlights & Details
AC/DC PCB power supply TracoPower TMG 30124 24 V/DC 1250 mA 30 W
- Output 24 V DC / 1.25 A
- Power 30 W
- Solder pins
Technical specifications
- Product type
AC/DC PSU (print)
- Input voltage (max.)
305 V AC
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 23.5 x 45.0 x 64.0 mm
- Output voltage (max.)
24 V DC
- Connection
Solder pins
30 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Min. operating temperature (derating)
-40 °C
- Weight
130 g
- Width
45.0 mm
- Height
64.0 mm
- Length
23.5 mm
- Type
TMG 30124
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3371558 TracoPower TMG 30124 AC/DC PSU (print) 24 V DC 1.25 A 30 W
User & Safety Instructions
User & Safety Instructions 3371558 TracoPower TMG 30124 AC/DC PSU (print) 24 V DC 1.25 A 30 W
Warranty Terms
Warranty Terms 3371558 TracoPower TMG 30124 AC/DC PSU (print) 24 V DC 1.25 A 30 W
Description
Compact, fully cast power supplies with high packing density
PCB mounting using soldering pins
Input filter in accordance with EN 55022, class B
Safety standards according to IEC/EN/UL 60950-1
Short circuit and surge protection
This text is machine translated.
PCB mounting using soldering pins
Input filter in accordance with EN 55022, class B
Safety standards according to IEC/EN/UL 60950-1
Short circuit and surge protection
