TracoPower TMR 12-2413WI DC/DC converter 15 V DC 0.8 A 12 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 40.99 / piece)
€ 409.90
incl. VAT
14-day return policy included
Highlights & Details
DC/DC converter, TMR 12WI series
- Output 15 V DC / 0.8 A
- Power 12 W
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
36 V DC
- Max. output current
0.8 A
- Output current (max.) - rounded
800 mA
- Min. input voltage
9 V DC
- Dim
(L x W x H) 22 x 9.60 x 12 mm
- Output voltage (max.)
15 V DC
12 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
+85 °C
- Operating temperature (min.)
-40 °C
- Weight
7.2 g
- Width
9.60 mm
- Height
12 mm
- Length
22 mm
- Type
TMR 12-2413WI
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3373017 TracoPower TMR 12-2413WI DC/DC converter 15 V DC 0.8 A 12 W
User & Safety Instructions
User & Safety Instructions 3373017 TracoPower TMR 12-2413WI DC/DC converter 15 V DC 0.8 A 12 W
Warranty Terms
Warranty Terms 3373017 TracoPower TMR 12-2413WI DC/DC converter 15 V DC 0.8 A 12 W
Description
The TMR 12WI series offers insulated DC/DC converters with 12 watts of power and regulated outputs. This series offers a power density of 4.73 W/cm³ in an ultra-compact SIL-8 metal housing with a base area of 2.0 cm². Efficiency of up to 90% allows a working temperature range of –40° to +65°C without power reduction in convection cooling. Other features include external on/off function and I/O isolation of 1600 VDC. Owing to its very compact dimensions this series is suitable for a number of applications, where space is critical.
This text is machine translated.
This text is machine translated.
Features
- Ultra-compact housing (SIL-8)
- 4:1 input ranges
- Exactly regulated outputs
- Input/Output insulation 1600 VDC)
- Protection against overload and short circuit
- Remote on/off
Scope of delivery
- 10 pieces
