TracoPower TRI 15-1215 DC/DC converter (print) 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 68.90 / piece)
€ 689.00
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TRI 15-1215
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
- Efficiency (max.)
88 %
15 W
- Insulation voltage
4200 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.80 x 25.40 x 12 mm
- Height
12 mm
- Length
50.80 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Output voltage (max.)
24.0 V DC
- Output voltage (min.)
24.0 V DC
- Weight
30 g
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3372360 TracoPower TRI 15-1215 DC/DC converter (print) 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3372360 TracoPower TRI 15-1215 DC/DC converter (print) 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372360 TracoPower TRI 15-1215 DC/DC converter (print) 625 mA 15 W No. of outputs: 1 x Content 1 pc(s)
