TracoPower TSR 2-0518 DC/DC converter (print) 5 V DC 15 V DC 2 A No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 11.76
30
6% = € 0.65
€ 11.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 11.76 / piece)
€ 117.60
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TSR 2-0518
- Nominal voltage
5 V DC
- Min. input voltage
21.6 V DC
- Input voltage (max.)
26.4 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
2 A
- Output current (max.) - rounded
2 A
- Efficiency (max.)
92 %
- Enclosure
SIL
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 14 x 14.2 x 7.5 mm
- Height
7.5 mm
- Length
14 mm
- Width
14.2 mm
- Output voltage (max.)
1.8 V DC
- Output voltage (min.)
1.8 V DC
- Weight
2.6 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372937 TracoPower TSR 2-0518 DC/DC converter (print) 5 V DC 15 V DC 2 A No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372937 TracoPower TSR 2-0518 DC/DC converter (print) 5 V DC 15 V DC 2 A No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372937 TracoPower TSR 2-0518 DC/DC converter (print) 5 V DC 15 V DC 2 A No. of outputs: 1 x Content 1 pc(s)
Description
Compact SIL casing, pin-compatible with LMxx linear regulators. No heat sink required. Integrated filter capacitors, excellent behavior in the case of input and load change, short-circuit proof.
