Visaton AL 130 M - 8 Ohm 6 inch 15.24 cm Mid-range speaker 60 W 8 Ω Aluminium diaphragm
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 142.85 / piece)
€ 142.85
plus VAT.
Only 10 Piece(s) available
Visaton AL 130 m high-end mid-woofer
Highlights & Details
- Especially suitable as a cone mid-range speakers in 3-way high-End-Systemen for frequency range up to 5000 Hz
Technical specifications
- Product type
Mid-range speaker
- Speaker size (inch)
6 inch
- Speaker size (cm)
15.24 cm
- RMS capacity
60 W
- Max. load
90 W
- Min. frequency
500 Hz
- Max. frequency
8000 Hz
- Impedance
8 Ω
- Sound pressure
86 dB
- Recess diameter
15.5 mm
- Recess depth
70 mm
- Weight
981 g
- Features
Aluminium diaphragm
- Frequency range
500 Hz - 8000 Hz
Documents & Downloads
Datasheet
Datasheet 311610 Visaton AL 130 M - 8 Ohm 6 inch 15.24 cm Mid-range speaker 60 W 8 Ω Aluminium diaphragm
User & Safety Instructions
User & Safety Instructions 311610 Visaton AL 130 M - 8 Ohm 6 inch 15.24 cm Mid-range speaker 60 W 8 Ω Aluminium diaphragm
Description
High-end-mid-range. Anodised aluminum diaphragm. Aludruckgusskorb.
