Vogt Verbindungstechnik 3867F.68 Blade receptacle PCB-SMD Connector width: 6.3 mm Connector thickness: 0.8 mm 180 ° Not
EAN:
Part number:
Item no:
Product type
Blade receptacle
Connector width
6.3 mm
Insulation type
Not insulated
Content
1 pc(s)
Factory colour
Metal
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
15
-
€ 0.22
45
9% = € 0.02
€ 0.20
75
14% = € 0.03
€ 0.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 15
Total (€ 0.22 / piece)
€ 0.24
-8 %
€ 3.30
plus VAT.
Highlights & Details
Vogt Verbindungstechnik 3867F.68 Blade receptacle PCB-SMD Connector width: 6.3 mm Connector thickness: 0.8 mm 180 ° Not insulated Metal 1 pc(s)
- Metal
- 6.3 mm x 0.8 mm
- -
Our service for you
Technical specifications
- Product type
Blade receptacle
- Connector width
6.3 mm
- Factory colour
Metal
- Connector thickness
0.8 mm
- Insulation type
Not insulated
- Connection angle
180°
- Contact material
Brass tin plated
- Content
1 pc(s)
- Manufacturer part #
3867F.68
- Size
6.3 x 0.8 mm
- Features
PCB-SMD
- Type
3867F.68
- Material (details)
Brass, tin-plated
- Type
6.3 x 0.8 mm
- Cross section
-
- Connection
-
Documents & Downloads
Datasheet
Datasheet 730042 Vogt Verbindungstechnik 3867F.68 Blade receptacle PCB-SMD Connector width: 6.3 mm Connector thickness: 0.8 mm 180 ° Not
User & Safety Instructions
User & Safety Instructions 730042 Vogt Verbindungstechnik 3867F.68 Blade receptacle PCB-SMD Connector width: 6.3 mm Connector thickness: 0.8 mm 180 ° Not
Description
Tin-plated brass.
