WAGO 2010-1306 Triple port continuity 10 mm Push-in connector Yellow 25 pc(s) Piece
Packaging type
Piece
Product type
Triple port continuity
Connection
Push-in connector
Cross section (flexible) (max.)
16 mm²
Cross section (inflexible) (max.)
16 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Packaging type
Piece
- Product type
Triple port continuity
- Features
+ push-in spring bracket
- Connection
Push-in connector
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
16 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (inflexible) (max.)
16 mm²
- Clamp width
10 mm
- No. of rows
1
- Number of pins
3
- Factory colour
Yellow
- Nominal current
57 A
- Nominal current - rounded value
57 A
- Nominal voltage
800 V
- Min. stripping length
17 mm
- Stripping length (max.)
19 mm
- Manufacturer part #
2010-1306
- Content
25 pc(s)
- Type
2010-1306
- Dim
(L x W x H) 89 x 10 x 36.90 mm
- Width
10 mm
- Height
36.90 mm
- Length
89 mm
- Flammability rating
V0
- Connector colour
Yellow
- Insulation material
Thermoplastic
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1931753 WAGO 2010-1306 Triple port continuity 10 mm Push-in connector Yellow 25 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 1931753 WAGO 2010-1306 Triple port continuity 10 mm Push-in connector Yellow 25 pc(s) Piece
