Name: WAGO 285-634 Continuity 16 mm Pull spring Configuration: N Blue 15 pc(s) Piece
Brand: WAGO
SKU: 537211
Availability: BackOrder

A cross-section of an electrical terminal block with visible internal mechanisms and connections. Suitable for industrial applications.

Packaging type

Piece

Product type

Continuity

Connection

Pull spring

Cross section (flexible) (max.)

35 mm²

Cross section (inflexible) (max.)

35 mm²

Datasheet (PDF)

Dispatches on Wed 11 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 15 pc(s))

Set(s)

Total (€ 13.33 / piece)

€ 199.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

2-conductor through terminal block

285-634
Industrial packaging with 15 pieces

Technical specifications

2-COND.TERM/BLK INT/END PLATE BLUE

Packaging type: Piece

Product type: Continuity

Connection: Pull spring

Configuration: N

Cross section (flexible) (min.): 6 mm²

Cross section (flexible) (max.): 35 mm²

Cross section (inflexible) (min.): 6 mm²

Cross section (inflexible) (max.): 35 mm²

AWG (min.): 10

AWG max.: 2

Clamp width: 16 mm

No. of rows: 1

Pins per row: 2

Number of pins: 2

Factory colour: Blue

Nominal current: 125 A

Nominal current - rounded value: 125 A

Nominal voltage: 1000 V

Stripping length (max.): 23 mm

Manufacturer part #: 285-634

Content: 15 pc(s)

Industrial packaging: Yes

Type: 285-634

Dim: (W x H) 16 mm x 53 mm

Width: 16 mm

Height: 53 mm

Contamination level: 3

Connector colour: Blue

UKCA: yes
