WAGO 756-5510/040-020 Sensor/actuator connector (pre-fab) M8 Plug, right angle, Socket, right angle 2.00 m No. of pins (

A black, round cable with plug connectors at both ends that can be used for technical devices.
Two round connectors: on the left an 'M8 socket' with numbered pins 3, 4, 2, 1 in a clockwise direction; on the right an 'M12 plug' with pins 4, 3, 1, 2 in a clockwise direction.
'Pin 1 to 5: 0.25 mm²' shows connections: Pin 1 brown, Pin 2 white, Pin 3 blue, Pin 4 black. Wiring diagram.
Technical drawing of a cable with connectors, showing dimensions: Length (L*), 23.5 mm, 31.5 mm, Ø 9.6 mm, Ø 15 mm, 16.5 mm, 33.1 mm.
1/4
Product type
Sensor/actuator connector (pre-fab)
Connector type
Plug, right angle
Socket, right angle
Connector standard
Sensor connector
Connection side A
M8 socket, right angle
Connection side B
M8 socket, right angle
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Thu 10 Dec
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 10 pc(s))
Total (€ 48.90 / piece)
€ 489.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Sensor/actuator cable

  • 756-5510/040-020
  • Industrial packaging, pack of 10

Technical specifications

  • M8 BUCHSE WINKL./M12 STECK.WINKL.,2M
Type

756-5510/040-020

Product type

Sensor/actuator connector (pre-fab)

Connector type

Plug, right angle

Socket, right angle

Connector standard

Sensor connector

Connection side A

M8 socket, right angle

Connection side B

M8 socket, right angle

No. of pins

4

Cable length

2.00 m

Jacket material

PUR

Nominal voltage

250 V

Nominal current

4 A

Nominal current - rounded value

4 A

Cross-section (sensor/actuator wiring)

0.34 mm²

Thread type connection side

M8

Cable colour

Black

IP67

Features

Suitable for drag chains

Min. temperature

+90 °C

Max. temperature

-50 °C

Seal type

Screw-on

Manufacturer part #

756-5510/040-020

Industrial packaging

Yes

Content

10 pc(s)

Cable diameter (details)

4.7 mm

Documents & Downloads

Datasheet

Datasheet 546556 WAGO 756-5510/040-020 Sensor/actuator connector (pre-fab) M8 Plug, right angle, Socket, right angle 2.00 m No. of pins (

User & Safety Instructions

User & Safety Instructions 546556 WAGO 756-5510/040-020 Sensor/actuator connector (pre-fab) M8 Plug, right angle, Socket, right angle 2.00 m No. of pins (

Description

Both ends fitted, 4-pin M8-socket, angled, M12 connector, angled, 2 m.
