Zettler Electronics AZ733-2CE-9DE PCB relay 9 V DC 12 A 2 change-overs 1 pc(s)
EAN:
Part number:
Item no:
Product type
PCB relay
Coil nominal voltage
9 V DC
Control mode
monostable, 1 coil
Contact type
2 change-overs
Switching voltage (max.)
150 V DC
380 V AC
Datasheet (PDF)
253 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.03
5
7% = € 0.27
€ 3.76
10
9% = € 0.37
€ 3.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.03 / piece)
€
Highlights & Details
PCB Relay 9 V DC 12 A
- Sealed Version with TÜV, UL and CUR approval
Technical specifications
- Product type
PCB relay
- Type
AZ733-2CE-9DE
- Coil nominal voltage
9 V DC
- Min. pick-up voltage
6.3 V DC
- Max. pick-up voltage
17.4 V DC
- Control mode
monostable, 1 coil
- Resistance (coil)
160 Ω
- Contact type
2 change-overs
- Contact material
AgSnO
- Switching voltage (max.)
150 V DC
380 V AC
- Switching current (max.)
12 A
- Max. switching capacity
300 W
2500 VA
- Connection
Solder pins
- Insulation voltage
1000 V
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Length
29 mm
- Width
13 mm
- Height
25.9 mm
- Dim
(L x W x H) 29 x 13 x 25.9 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 2445483 Zettler Electronics AZ733-2CE-9DE PCB relay 9 V DC 12 A 2 change-overs 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2445483 Zettler Electronics AZ733-2CE-9DE PCB relay 9 V DC 12 A 2 change-overs 1 pc(s)
