Name: akYtec PR205.24.1.2 156316 PLC control relay 24 V DC
Brand: akYtec
SKU: 3553334
Availability: InStock

'Programmable Logic Controller (PLC) by akYtec, model PR200, showing status "Work: ON" and condition "NORMAL" on display screen.'

'PR200 series controller showing interface with temperature settings, operation modes, and connection terminals for industrial use.'

1/2

Fast track dispatch on Thu 15 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 415.00 / piece)

€ 415.00

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

PR205.24.1.2, programmable relay

HMI: Graphic screen and buttons
Graphic color screen, 2.4" diagonal, 320×240
6 mechanical buttons, user-adjustable
5 LEDs: 3 service LEDs, 2 user LEDs
Optimal combination of inputs and outputs
4 analog inputs: PT1000, NTC/PTC, 4...20 mA/ 0...10 V, discrete mode
3 universal analogue outputs: 4...20 mA/0...10 V
6 digital inputs (power supply 24 V)
2 fast digital inputs up to 100 kHz
8 digital outputs (E/M relays and transistor switches)
Communication functions
Ethernet interface, Master/slave mode, Modbus TCP:
Direct access to the akYtec cloud service
Connection to a PC for program configuration and recording
Configuration in akYtec ToolPro
Process visualization with control panels and SCADA
Expansion of I/O with akYtec MX210 modules
Up to 2 RS-485 ports, Master/slave mode, Modbus RTU/ASCII:
Integration with SCADA systems
Process visualization with control panels
Expansion of the inputs and outputs with akYtec MX110 modules
Control of external devices: Frequency converter, sensors, etc.
Connection to PC for configuration and program recording
Compact modular housing with a width of 7 modules
Removable terminal blocks for easy installation
Quick battery change
Operation
2 Power supply modifications: ~/=24 V.
Expansion of the input/output channels using PRM modules
Operation in unheated rooms: -20...+55 ºС
Configuration and program storage via USB, Ethernet

Technical specifications

Min Operating voltage 20 V DC
Max. Operating voltage 36 V DC
Operating voltage: 24 V DC
Display: Yes
Product type: PLC controller
Number of relay outputs (max.): 8
Height: 58 mm
Length 123 mm.
Width 108 mm
IP protection class IP20
Manufacturer part number: 156316
Dimensions 123 x 108 x 58 mm (L x W x H)
Real-time clock: Yes
Interfaces: 1 x Ethernet, 2 x RS485
Number of digital inputs (max.): 6
Number of fast digital inputs (max.): 2
Number of analogue inputs (max.) (4...20 mA, 0...10 V, Pt1000, NTC, PTC, 0...300 kOhm, etc.): 4
Supported protocols: Modbus TCP/RTU / ASCII (Master / slave)
Clock: Real-time clock
Program memory: ROM 224 kB / Retain 60 kB
Model type: PR205.24.1.2
Number of expansion modules: 2
Connection type (details): DIN rail (switchboard/distribution box)
Max. Surrounding temperature +55 °C
Min Surrounding temperature -20 °C
Number of analogue outputs (max.) (4...20 mA/0...10 V): 3

Product type: PLC control relay

No. of analogue inputs: 4

No. of analogue outputs: 3

No. of digital inputs (max.): 6

No. of relay outputs (max.): 8

Supported protocols: ModBUS TCP / RTU / ASCII (Master / slave)

Min. operating voltage: 20 V DC

Operating voltage: 20 - 36 V DC

Max. operating voltage: 36 V DC

Operating voltage: 24 V DC

Height: 58 mm

Length: 123 mm

Width: 108 mm

: IP20

Type: PR205.24.1.2

Manufacturer part #: 156316

Dim: (L x W x H) 123 x 108 x 58 mm

Display: Yes

Real-time clock: Yes

Max. ambient temperature: +55 °C

Min. ambient temperature: -20 °C

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3553334 akYtec PR205.24.1.2 156316 PLC control relay 24 V DC

Description

The SIMATIC S7-200 family offers a broad spectrum of modules suitable for the most varied applications. The newly available CPU types and expansion modules enable universal automation concepts with 10 to 248 inputs/outputs. The products of the S7-200 family which are optimally matched to each other also make it easy to change and expand the automation solution in the future.
Area of application e.g.:small and special machines: Packaging, encompassing and wrapping machines .Food industry: kneading, cutting machines, Mixing .Laboratory: Lab mixer, steam ovens, vacuum pumps, suction mechanisms.
The CPUs are each offered in 5 different variants, with various connection and control voltages. The PPI interface built into all CPUs enables point-to-point connections to PG/PC, SIMATIC OP, expanded SIMATIC S7-200 and user-defined end devices (printer, bar code reader). With PG/PC or OP as master, a maximum of 31 SIMATIC S7-200 devices can be connected together. If additional inputs/outputs are required, a variety of different expansion modules is available. These are simply linked to the CPU through a connector.
