B + B Thermo-Technik Heating element cable Black 0230 0215 Sold per metre
Part number:
Item no:
Product type
Heating element cable
No. of leads
2 x
Outside Ø
3.6 mm
Content
Sold per metre
Cable features
Flexible
Datasheet (PDF)
Quantity (meter)
Unit Price
Package size (plus VAT.)
1
1 M = € 5.45
€ 5.45
5
1 M = € 5.13
€ 5.13
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (1 m = € 5.45)
€ 5.45
plus VAT.
Highlights & Details
Thermal cable type J NiCr, 2 x 0.22 mm², PVC/PVC
Our service for you
Technical specifications
- Product type
Heating element cable
- No. of leads
2 x
- Content
Sold per metre
- Cable features
Flexible
- Outside Ø
3.6 mm
- Packaged
No
- Manufacturer part #
0230 0215
- Factory colour
Black
- Insulation material
PVC
- Insulation
PVC
- Core layout
7 x 0.20 mm
- Material (details)
PVC
- Max. length sold by the metre
100 m
- Sold per metre
Yes
- RoHS-compliant
Yes
- Max. temperature range (flexible installation)
105 °C
- Min. temperature range (flexible installation)
-20 °C
- Max. temperature range (fixed installation)
+105 °C
- Type
Thermoleitung Typ J NiCr
Documents & Downloads
Datasheet
Datasheet 3736853 B + B Thermo-Technik Heating element cable Black 0230 0215 Sold per metre
User & Safety Instructions
User & Safety Instructions 3736853 B + B Thermo-Technik Heating element cable Black 0230 0215 Sold per metre
Description
The thermal cable type J can be used at ambient temperatures from - 20 to +105 °C. The two conductors of this thermal cable are made of the same alloy made of thermocouples of type J (Fe-CuNi), whereby the accuracy class 1 is fulfilled. The extension of existing thermocouples is possible and does not lead to any additional errors in the measurement. The cable has a robust and flexible PVC insulation.
