Name: BKL Electronic Pin strip (standard) Total number of pins 8 Contact spacing: 2.50 mm 072506-U 1 pc(s)
Brand: BKL Electronic
SKU: 1548696
Availability: InStock

Orange multi-pin connector used for electronic circuits.

Image similar

Product type

Pin strip (standard)

Connector type

Pin strip, straight

No. of rows

2.50 mm

Total number of pins

Datasheet (PDF)

Fast track dispatch on Thu 15 Oct

250 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 5

Total (€ 0.45 / piece)

€ 2.25

incl. VAT

14-day return policy included

Report legal concerns

Alternative article by TRU COMPONENTS

TRU COMPONENTS Pin strip (standard) Total number of pins 8 Contact spacing: 2.50 mm 1582662 1 pc(s)

€ 0.73

incl. VAT plus

Highlights & Details

Straight connector pin strip

Content: 1 pc(s)
No. of rows: 1
Total number of pins: 8

Our service for you

Technical specifications

Product type: Pin strip (standard)

Connector type: Pin strip, straight

No. of rows: 1

Connector system: wire-to-board

CS: 2.50 mm

Pins per row: 8

Total number of pins: 8

Pin Ø: 0.64 mm

Pin shape: Square

Content: 1 pc(s)

Connection: Print

Case material: Nylon 6.6 UL 94V-0

Manufacturer part #: 072506-U

Contact material: Brass

Connector contact surface: Nickel plated

RoHS-compliant: Yes

Connector orientation: Perpendicular (to the PCB)

Max. temperature: +85 °C

Min. temperature: -40 °C

Type: 072506-U

Variants(All information include VAT, plus shipping costs)

Connector type

Total number of pins

Pin shape

BKL Electronic Pin strip (standard) Total number of pins 8 Contact spacing: 2.50 mm 072506-U 1 pc(s)

Item no:1548696

Fast track dispatch on Thu 15 Oct

250 Piece(s)Conrad Electronic

This article

Pin strip, straight

2.50 mm

Square

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.45^*

BKL Electronic Pin strip (standard) Total number of pins 10 Contact spacing: 2.50 mm 072508-U 1 pc(s)

Item no:1548703

Fast track dispatch on Thu 15 Oct

96 Piece(s)Conrad Electronic

Pin strip, straight

2.50 mm

Square

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.43^*

BKL Electronic Pin strip (standard) Total number of pins 2 Contact spacing: 2.50 mm 072500-U 1 pc(s)

Item no:1548699

Fast track dispatch on Thu 15 Oct

474 Piece(s)Conrad Electronic

Pin strip, straight

2.50 mm

Square

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.33^*

BKL Electronic Pin strip (standard) Total number of pins 2 Contact spacing: 2.50 mm 072501-U 1 pc(s)

Item no:1548700

Available soon

Conrad Electronic

Pin strip, right angle

2.50 mm

Square

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.36^*

BKL Electronic Pin strip (standard) Total number of pins 5 Contact spacing: 2.50 mm 072504-U 1 pc(s)

Item no:1548689

Fast track dispatch on Thu 15 Oct

455 Piece(s)Conrad Electronic

Pin strip, straight

2.50 mm

Square

Piece(s)

Minimum order quantity: 7

Multiple: 1

€ 0.25^*

BKL Electronic Pin strip (standard) Total number of pins 6 Contact spacing: 2.50 mm 072543-U 1 pc(s)
