Crydom Solid State Electronic Load Relay, Panel Mount

A black Crydom solid state relay with screw terminals, suitable for 240V and 25A, shows connections and technical specifications.
'Diagram of an electrical component with dimensions. Shows connections, mounting points, and base plate. Designed for specific installation.'
1/2
Image similar
Packaging type
Piece
Product type
SSR
Control voltage (min.)
3 V DC
Control voltage (max.)
32 V DC
Switching voltage (max.)
280 V AC
Datasheet (PDF)
EAN:
Part number:
Item no:
Available soon
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 63.99 / piece)
€ 63.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Crydom Solid State Electronic Load Relay, Panel Mount

Our service for you

Technical specifications

Packaging type

Piece

Product type

SSR

Type

D2410

Switching type

Zero crossing

Control voltage (min.)

3 V DC

Control voltage (max.)

32 V DC

Control voltage range

3 - 32 V DC

Surge current (max.)

250 A

Switching voltage (min.)

24 V AC

Switching voltage (max.)

280 V AC

Current load (max.)

10 A

Output voltage (max.)

280 V AC

Max. output current

10 A

Min. temperature

-40 °C

Max. temperature

+80 °C

Width

45.7 mm

Height

23 mm

Length

58.4 mm

RoHS-compliant

Yes

Content

1 pc(s)

Type

Switches at voltage zero.

Ambient temperature

-40 - +80 °C

Documents & Downloads

Datasheet

Datasheet 186473 Crydom Solid State Electronic Load Relay, Panel Mount

User & Safety Instructions

User & Safety Instructions 186473 Crydom Solid State Electronic Load Relay, Panel Mount

Description

The widespread series 1 is Crydoms featured load relais-family. with modern SMD-technology, it ensures reliablity in the most difficult applications. Visually separate SCR-output for high switching loads in Industrial applications. "Hockey-Puck" Standard-Industrial housing for Chassis- or heat sink-mounting.

Hints

Approvals UL, CSA, VDE
