Buy Diotec B80C3700A Diode bridge SIL 4 160 V 3.7 A 1-phase | Conrad Electronic

There is a Conrad shop in your region. You can shop in your own language, have access to your local customer service and enjoy local transport for your purchase.

Go to local shop

Conrad
To search for the product, enter a catchphrase, an article number, an EAN or a part number
My account

Log in / Register
Shopping cart

Subscribe to the newsletter and receive a €5 voucher Subscribe to the newsletter and receive a €5 voucher
Procurement

Order & eProcurement

All order and procurement services
Services

All Services
Offers %

Rectifier IC with the inscription 'B 500 C7000-4000', shows four electrical connection pins, two with plus/minus symbols, two with wavy lines.

Image similar

Rectifier IC with the inscription 'B 500 C7000-4000', shows four electrical connection pins, two with plus/minus symbols, two with wavy lines.

'Electronic component with dimensions: Width 40 mm, Height 20 mm. Connections from left: Minus, Alternating Current, Alternating Current, Plus. Distance between connections: 7.5 mm, 10 mm, 7.5 mm.'

1/2

Image similar

Diotec

Datasheet (PDF)

European union

Fast track dispatch on Fri, 11 Sep

471 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 1.92 / piece)

€ 1.92

plus VAT.

Report legal concerns

Technical specifications

Type: B80C3700A

Enclosure: SIL 4

Manufacturer: Diotec

Manuf. code: DIO

Configuration (diode): 1-phase

U(RRM): 160 V

Forward current I(F): 3.7 A

I(FSM) 50Hz: 150 A

I(FSM) 60Hz: 165 A

Reverse leakage current I(r): 5 µA

Reverse leakage current I(r) reference: 160 V

Operating temperature (min.): -50 °C

Operating temperature (max.): +150 °C

Mounting type: Through-hole

RoHS-compliant: Yes

Nominal current (details): (free-standing) 2.2 A/(chassis assembly) 3.7 A

Voltage: 80 V

UKCA: yes

Product type: Diode bridge

Documents & Downloads

Datasheet

European union

Datasheet 501891 Diotec B80C3700A Diode bridge SIL 4 160 V 3.7 A 1-phase

User & Safety Instructions

User & Safety Instructions 501891 Diotec B80C3700A Diode bridge SIL 4 160 V 3.7 A 1-phase

Description

Rectifiers from leading manufacturers. Full details free to download from our comprehensive product documents library.
