Two cylindrical electronic components with long metal wires at their ends, presumably diodes, on a white background.

Image similar

Two cylindrical electronic components with long metal wires at their ends, presumably diodes, on a white background.

Image similar

Enclosure

DO 41

Forward current I(F)

1 A

Reverse voltage U(R)

600 V

Forward voltage U(F)

1.70 V

Mounting type

Through-hole mounting

Datasheet (PDF)

English

Diotec

2450 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Minimum order quantity: 750

Total (€ 0.04725 / piece)

€

Report legal concerns

Technical specifications

Type AxialDO-41 housingPeriodic Peak Reverse Voltage - VRRM 600 VContinuous current - IFAV 1.00 AJunction temperature - Tjmax 175 °CReverse delay time - trr: 75 nsSurge current - IFSM 30.00 AForward voltage - VF 1.70 VIF 1.00 AReverse current - IR 5,000 µAVR 600 VLock layer capacity - CJ: PFVR V

Type: UF4005

Enclosure: DO 41

Manufacturer: Diotec

Forward current I(F): 1 A

Reverse voltage U(R): 600 V

Forward voltage U(F): 1.70 V

Reverse leakage current I(r): 5 µA

Operating temperature (max.): 175 °C

Mounting type: Through-hole mounting

I(FSM) 50Hz: 30 A

Reverse recovery time T(rr): 75 ns

RoHS-compliant: Yes

Product type: Rectifier

Documents & Downloads

Datasheet

English

Datasheet 2808836 Diotec Rectifier UF4005 DO 41 600 V 1 A
