Name: DOGA DC gearmotor Typ 111 DO 111.3763.3B.00 / 3001 24 V 2 A 6 Nm 25 U/min Shaft diameter: 9 mm 1 pc(s)
Brand: DOGA
SKU: 198317
Availability: InStock

A grey electric motor with a cylindrical housing and multiple screws is depicted.

Datasheet (PDF)

Fast track dispatch on Fri 16 Oct

140 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 154.99 / piece)

€ 154.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

DOGA motor

Innumerable Areas of use
Compact dimensions
Extremely good performance values
This text is machine translated.

Technical specifications

Shaft version: With key 3

Product type: DC gearmotor

Type: Typ 111

Nominal voltage: 24 V

Nominal current: 2 A

Nominal current - rounded value: 2 A

Nominal power: 16 W

Nominal RPM: 25 U/min

Drive torque: 6 Nm

Shaft design: With key 3

Dim: (L x W x H) 178 x 60 x 100.6 mm

Width: 60 mm

Manufacturer part #: DO 111.3763.3B.00 / 3001

Type: DC gear motor

Shaft Ø: 9 mm

Nominal torque: 6 Nm

Idle speed: 25 U/min

Height: 100.6 mm

Length: 178 mm

Nominal RPM: 25 U/min

Nominal voltage (details): 24 V

Nominal current (details): 2 A

Variants(All information include VAT, plus shipping costs)

Nominal current - rounded value

Shaft Ø

Nominal torque

Nominal power

Nominal RPM

Product type

Nominal voltage

DOGA DC gearmotor Typ 111 DO 111.3763.3B.00 / 3001 24 V 2 A 6 Nm 25 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198317

Fast track dispatch on Fri 16 Oct

140 Piece(s)Conrad Electronic

This article

2 A

9 mm

6 Nm

16 W

25 U/min

DC gearmotor

24 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 154.99^*

DOGA DC gearmotor Typ 111 DO 111.3761.2B.00 / 3018 12 V 5 A 5 Nm 40 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198458

Fast track dispatch on Fri 16 Oct

37 Piece(s)Conrad Electronic

5 A

9 mm

5 Nm

21 W

40 U/min

DC gearmotor

12 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 149.99^*

DOGA DC gearmotor Typ 111 DO 111.3761.3B.00 / 3000 24 V 2.5 A 5 Nm 40 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198305

Fast track dispatch on Fri 16 Oct

9 Piece(s)Conrad Electronic

2.5 A

9 mm

5 Nm

21 W

40 U/min

DC gearmotor

24 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 159.99^*

DOGA DC gearmotor Typ 111 DO 111.3763.2B.00 / 3049 12 V 4 A 6 Nm 25 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198411

Fast track dispatch on Fri 16 Oct

22 Piece(s)Conrad Electronic

4 A

9 mm

6 Nm

16 W

25 U/min

DC gearmotor

12 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 149.99^*

DOGA DC gearmotor Typ 111 DO 111.9031.3B.00 / 3002 24 V 3 A 3 Nm 70 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198329

Fast track dispatch on Fri 16 Oct

9 Piece(s)Conrad Electronic

3 A

9 mm

3 Nm

22 W

70 U/min

DC gearmotor

24 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 164.99^*

DOGA DC gearmotor Typ 111 DO 111.9039.3B.00 / 3019 24 V 4 A 1.5 Nm 240 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198470

Fast track dispatch on Fri 16 Oct

34 Piece(s)Conrad Electronic

4 A

9 mm

1.5 Nm

38 W

240 U/min

DC gearmotor

24 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 234.99^*

DOGA DC gearmotor Typ 111 DO 111.9172.3B.00 / 3064 24 V 2.5 A 5 Nm 40 U/min Shaft diameter: 10 mm 1 pc(s)

Item no:198615

Fast track dispatch on Fri 16 Oct

7 Piece(s)Conrad Electronic

2.5 A

10 mm

5 Nm

21 W

40 U/min

DC gearmotor

24 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 265.00^*

DOGA DC gearmotor Typ 316 DO 316.2761.2H.00 / 3120 12 V 3.4 A 2 Nm 38 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198486

Fast track dispatch on Fri 16 Oct

1 Piece(s)Conrad Electronic

3.4 A

9 mm

2 Nm

8 W

38 U/min

DC gearmotor

12 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 139.99^*

DOGA DC gearmotor Typ 316 DO 316.2761.3H.00 / 3121 24 V 1.7 A 2 Nm 38 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198499

Fast track dispatch on Fri 16 Oct

16 Piece(s)Conrad Electronic

1.7 A

9 mm

2 Nm

8 W

38 U/min

DC gearmotor

24 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 129.99^*

DOGA DC gearmotor Typ 316 DO 316.9731.3H.00 / 3122 24 V 3 A 1.5 Nm 65 U/min Shaft diameter: 9 mm 1 pc(s)

Item no:198511

Fast track dispatch on Fri 16 Oct

17 Piece(s)Conrad Electronic

3 A

9 mm

1.5 Nm

10 W

65 U/min

DC gearmotor

24 V

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 129.99^*

Documents & Downloads

Datasheet

Datasheet 198317 DOGA DC gearmotor Typ 111 DO 111.3763.3B.00 / 3001 24 V 2 A 6 Nm 25 U/min Shaft diameter: 9 mm 1 pc(s)

User & Safety Instructions

User & Safety Instructions 198317 DOGA DC gearmotor Typ 111 DO 111.3763.3B.00 / 3001 24 V 2 A 6 Nm 25 U/min Shaft diameter: 9 mm 1 pc(s)

Download

Download 198317 DOGA DC gearmotor Typ 111 DO 111.3763.3B.00 / 3001 24 V 2 A 6 Nm 25 U/min Shaft diameter: 9 mm 1 pc(s)

Description

The DOGA DC motor was developed for industrial applications and falls back on over 50 years of experience and innumerable application areas. The permanent magnet technology permits a compact design with extremely good performance data. The motor is specially designed for applications with independent power supply, small dimensions, low weight as well as for use in industry and in vehicles of all kinds. This quality product is distinguished by its precise speed, silent running, short stop times with low moment of inertia and an extremely rugged design.

Features

Gear wheel made of synthetic material POM
Protection class IP40 and/ or IP53
Any service position
Characteristics of engines with impulse generating system (Type DO16241223B00/3065 and type DO11191723B00/3064): Magnetic impulse generator with hall sensors, 2 Channel 90° out-of-phase Resolution of 16 pulses per motor revolution; Integrated voltage regulator for a wide range of supply voltage (4.2 - 24 V); Integrated Schmitt trigger operates with external pull-up resistors; Output switching Open Collector; Inclusive of 4 m connection cord Type LIYCY 4 x 0.25 mm².

Description

Features

Gear wheel made of synthetic material POM
Protection class IP40 and/ or IP53
Any service position
Characteristics of engines with impulse generating system (Type DO16241223B00/3065 and type DO11191723B00/3064): Magnetic impulse generator with hall sensors, 2 Channel 90° out-of-phase Resolution of 16 pulses per motor revolution; Integrated voltage regulator for a wide range of supply voltage (4.2 - 24 V); Integrated Schmitt trigger operates with external pull-up resistors; Output switching Open Collector; Inclusive of 4 m connection cord Type LIYCY 4 x 0.25 mm².
