Name: Eaton EMR6-N1000-N-1 184756 PLC add-on module
Brand: Eaton
SKU: 2147043
Availability: BackOrder

A white and black electrical relay module labelled 'EMR5-N1000-N-1'. It has connections on the top and various switches at the front.

Technical drawing of an electrical component with precise dimensions in millimetres: 102.4 x 104.6 x 85.6.

1/2

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Tue 10 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 174.99 / piece)

€ 174.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Single-wire connection cross-section: 1 x 0.5-2.5 (1 x 18-14 AWG) mm2
Connection cross-section fine-wired with wire-end sleeve: 2 x 0.5-1.5 (2 x 18-16 AWG) mm2

Product type: PLC add-on module

Type: EMR6-N1000-N-1

Min. operating voltage: 110 V AC

Operating voltage: 110 - 240 V AC

Max. operating voltage: 240 V AC

Height: 85.60 mm

Length: 102.40 mm

Width: 22.50 mm

Dim: (L x W x H) 102.40 x 22.50 x 85.60 mm

Manufacturer part #: 184756

Max. ambient temperature: +60 °C

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2147043 Eaton EMR6-N1000-N-1 184756 PLC add-on module

User & Safety Instructions

User & Safety Instructions 2147043 Eaton EMR6-N1000-N-1 184756 PLC add-on module

Description

Level relay for monitoring the filling level or a mixing ratio of conductive liquids can be switched dry run protection overflow protection 5 kOhm-100 kOhm, supply voltage 220-240V AC

This text is machine translated.
