Name: Endress+Hauser Level sensor Capacitive FTE20 FTE20-BI13AF21
Brand: Endress+Hauser
SKU: 2988473
Availability: BackOrder

Sensor device with a blue housing and a rotatable impeller wheel with an orange warning lamp, used for level measurement in containers.

Product type

Level sensor

Max. operating voltage

24 V AC

Model

Capacitive

Type

FTE20

Operating voltage

24 V AC (max)

EAN:

Part number:

Item no:

Dispatches on Fri 6 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 535.00 / piece)

€ 535.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Rotary wing limit switch swing arm limit switch FTE20-BI13AF21 24VAC standard; 304 rope, 2000mm, can be shortened

Approval: ATEX II1/2D Ex ta/TB IIIC da/DB
Process connection; material: G1-1/2 external thread; PBT
Design, length: Rope, 2000 mm, can be shortened
Power supply: 24VAC
Measurement blades; material: Standard; 304

Technical specifications

Product type: Level sensor

Type: FTE20

Max. operating voltage: 24 V AC

Operating voltage: 24 V AC (max)

Enclosure material: PBT

Model: Capacitive

Cable length: 2000 mm

Min. temperature: -20 °C

Max. temperature: 60 °C

Content: 1 pc(s)

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2988473 Endress+Hauser Level sensor Capacitive FTE20 FTE20-BI13AF21

Description

The Soliswitch FTE20 is a swing arm switch for position detection in bulk materials. With its robust polymer housing and the compact design it is an ideal sensor for full, empty and demand messages. The optimized polymers make the device extremely robust and therefore suitable for use in areas subject to dust explosion hazards according to the latest standards.

This text is machine translated.

Features

Line-guided cable channel helps with the initial start-up, because it guides you to the clamps without clamping. A circuit diagram is included in the unit.
User-friendly thanks to undetachable screw cap, rotating housing and tool-free lid opening.
Easy testing during installation and - if necessary - quick fault search through function check very easily with a screwdriver. The paddle can be blocked without disassembling the device.
The visual rotating monitoring through the transparent lid is especially helpful in environments endangered by dust explosion.

Description

Features

Line-guided cable channel helps with the initial start-up, because it guides you to the clamps without clamping. A circuit diagram is included in the unit.
User-friendly thanks to undetachable screw cap, rotating housing and tool-free lid opening.
Easy testing during installation and - if necessary - quick fault search through function check very easily with a screwdriver. The paddle can be blocked without disassembling the device.
The visual rotating monitoring through the transparent lid is especially helpful in environments endangered by dust explosion.
