Endress+Hauser Level sensor Capacitive FTW33 FTW33-AA4MX2J shielded PNP

A cylindrical pressure sensor with a metal housing, labelling and connection at the top. Primarily used for pressure monitoring.
Product type
Level sensor
Max. operating voltage
30 V DC
Contact type
1 PNP
Outputs
PNP
Model
Capacitive
EAN:
Part number:
Item no:
Available soon
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 435.00 / piece)
€ 435.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Liquid Point FTW23/33 FTW33-AA4MX2J 10-30VDC capacitive limit switch; 3-conductor PNP thread M24, 316L install > accessories adapter

  • Approval: Ex-free range
  • Power supply; output: 10-30VDC; 3-wire PNP
  • Electrical connection: Connector M12, IP65/67 NEMA type 4 Encl.
  • Process connection: Thread M24, 316L mounting > accessories adapter

Technical specifications

Product type

Level sensor

Type

FTW33

Min. operating voltage

10 V DC

Max. operating voltage

30 V DC

Operating voltage

10 - 30 V DC

Contact type

1 PNP

Outputs

PNP

Model

Capacitive

Installation type

shielded

Min. temperature

-40.0 °C

Max. temperature

70.0 °C

IP65

IP67

Content

1 pc(s)

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2988781 Endress+Hauser Level sensor Capacitive FTW33 FTW33-AA4MX2J shielded PNP

User & Safety Instructions 2988781 Endress+Hauser Level sensor Capacitive FTW33 FTW33-AA4MX2J shielded PNP

Description

The Lilipoint FTW33 was developed for the food industry and meets all international hygiene requirements. This device is also ideally suited for applications in all other sectors. For use in pasty and adhesive media and media with strong adhesion.

This text is machine translated.

Features

  • Flush-mounted design allows the smelting of pipes
  • No individual adaptation to every Medium required
  • CIP and SIP cleanability guaranteed - up to protection class IP 69
