Image similar
FCI Pin strip (standard) DUBOX Total number of pins 5 Contact spacing: 2.54 mm 76382-305LF 1 pc(s)
Product type
Pin strip (standard)
Connector type
Pin strip, right angle
No. of rows
1
Series
DUBOX
CS
2.54 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 0.43 / piece)
€ 0.43
incl. VAT
14-day return policy included
Highlights & Details
Pin strip
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 5
Technical specifications
- Product type
Pin strip (standard)
- Connector type
Pin strip, right angle
- No. of rows
1
- Connector system
wire-to-board
- Series
DUBOX
- CS
2.54 mm
- Pins per row
5
- Total number of pins
5
- Width
9.34 mm
- Pin shape
Rectangular
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Content
1 pc(s)
- Dim
(L x W x H) 12.62 x 9.34 x 5.2 mm
- Connection
Print
- Case material
Polyester
- Manufacturer part #
76382-305LF
- Factory colour
Blue
- Industrial packaging
No
- Insulation material
Polyester
- Contact material
Phosphorus bronze
- Connector contact surface
Nickel plated
- Height
5.2 mm
- Length
12.62 mm
- Connector orientation
Parallel (to the PCB)
- Max. temperature
+125 °C
- Min. temperature
-40 °C
- Type
Dubox / PV / Bergstik
Documents & Downloads
Datasheet
Datasheet 1401592 FCI Pin strip (standard) DUBOX Total number of pins 5 Contact spacing: 2.54 mm 76382-305LF 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1401592 FCI Pin strip (standard) DUBOX Total number of pins 5 Contact spacing: 2.54 mm 76382-305LF 1 pc(s)
