FESTO Proximity sensor Inductive SMEO-1-S-LED-24-B 150848 modular assembly

A rectangular metal sensor with cable connection, labelled 'Festo SME-10'. Used for non-contact detection in automation systems.
Product type
Proximity sensor
Max. operating voltage
27 V AC
Model
Inductive
Type
SMEO-1-S-LED-24-B
Min. operating voltage
12 V AC
Datasheet (PDF)
EAN:
Part number:
Item no:
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 139.99 / piece)
€ 139.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
Only available for business customers
14-day return policy included
Report legal concerns

Highlights & Details

Proximity switch SMEO-1-S-LED-24-B

  • On a dark background, 'Official Partner' is positioned on the left, with the FESTO logo in orange on a white background on the right.

Technical specifications

  • Max. output current 1000 mA
  • Product weight: 20 g
  • Mounting type: with accessories
  • Max. circuit breaking capacity 27 W
Product type

Proximity sensor

Type

SMEO-1-S-LED-24-B

Min. operating voltage

12 V AC

Max. operating voltage

27 V AC

Operating voltage

12 - 27 V AC

Enclosure material

PET

Model

Inductive

Installation type

modular assembly

Features

LED indicator

Min. temperature

-20 °C

Max. temperature

+70 °C

IP67

Content

1 pc(s)

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 1894912 FESTO Proximity sensor Inductive SMEO-1-S-LED-24-B 150848 modular assembly

User & Safety Instructions

User & Safety Instructions 1894912 FESTO Proximity sensor Inductive SMEO-1-S-LED-24-B 150848 modular assembly

Information

Information 1894912 FESTO Proximity sensor Inductive SMEO-1-S-LED-24-B 150848 modular assembly

Description

Proximity switch SMEO-1-S-LED-24-B with reed contact and light-emitting diode, without mounting kit. Design = block construction, approval = RCM mark, CE mark (see declaration of conformity) = after EU EMC Directive, material note = copper and PTFE-free, measuring principle = Magnetic Reed

This text is machine translated.
