Name: FLIR E6 Pro IR camera -20 up to 550 °C 240 x 180 Pixel 9 Hz MSX®
Brand: FLIR
SKU: 2937113
Availability: InStock

A thermal imaging camera shows a building with colour-coded temperature ranges. Main function: temperature measurement.

A thermal imaging camera shows coloured temperature differences of a building on its display.

Two thermal imaging cameras, one displaying a colour temperature indicator on the screen, the other positioned sideways.

A black thermal imaging camera with a display showing a coloured thermal image of a building.

1/4

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

13 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 2,375.00 / piece)

€ 2,375.00

incl. VAT

14-day return policy included

Report legal concerns

Alternative article by VOLTCRAFT

VOLTCRAFT WB-420 IR camera -20 up to 550 °C 256 x 192 Pixel 25 Hz Built-in digital camera, Touchscreen, Wi-Fi, Withstand

€ 795.00

incl. VAT plus

Highlights & Details

FLIR E6 Pro – Infrared camera with 240x180 IR resolution and Ignite Cloud

9 Hz Thermal imaging camera
Temperature reading range -20 up to 550 °C
240 x 180 Pixel Bolometer matrix
Thermal sensitivity 50 mK

Technical specifications

Type: E6 Pro

Product type: IR camera

Bolometer array: 240 x 180 Pixel

Temperature reading range (max.): 550 °C

Temperature reading range (min.): -20 °C

Optics: 33 x 25°

Frame rate: 9 Hz

Display resolution: 640 x 480 Pixel

: IP54

Thermal sensitivity: 50 mK

Dim: (L x W x H) 244 x 95 x 140 mm

Display: Colour LCD

Focus: Automatic

Weight: 590 g

Basic accuracy: 2 %

Accuracy ± °C: 2 °C

Temperature reading range: -20 up to 550 °C

Min. focusing distance: 0.36 m

Width: 95 mm

Height: 140 mm

Length: 244 mm

Features: MSX®

: 0.59 kg/m

: -15-50 °C

: IP54

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2937113 FLIR E6 Pro IR camera -20 up to 550 °C 240 x 180 Pixel 9 Hz MSX®

User & Safety Instructions

User & Safety Instructions 2937113 FLIR E6 Pro IR camera -20 up to 550 °C 240 x 180 Pixel 9 Hz MSX®

Description

With the FLIR E6 Pro infrared camera with 240x180 IR resolution and Ignite cloud you can detect imminent failures earlier, because the optics are always in focus and the large, sharp touch-screen with 640x480 pixels is available. Save time by connecting to the cloud to automatically save, edit, and share images in FLIR Ignite or Thermal Studio. OTA (Over The Air) updates ensure that your camera is always equipped with the latest features. The FLIR MSX image enhancement provides extraordinary thermal detail with a visual 5 MP camera and an LED lamp for improved decision support. Simplify your workflow by using the touchscreen to pan and zoom, and to add comments to images that are automatically inserted into reports. Robust, reliable yet lightweight design for one-handed image capture.

This text is machine translated.

Features

Identify where the problems are, thanks to FLIR MSX® (Multispectral Dynamic Imaging). Thus important visual details are transferred in thermal images
1-touch level/span – this saves you time when making manual adjustments
The touch-screen with a resolution of 640 × 480 improves the inspection efficiency. Allows you to add detailed notes to each image
Edit, store, organize and share images using the FLIR Ignite cloud service
Quickly create reports from any device in FLIR Ignite, or create advanced reports from a PC in FLIR Thermal Studio
240x180 IR resolution;FLIR MSX®;FLIR Ignite;Touch screen;1-touch level/span;Digital camera 5MP;3.5 inch display;9Hz

Scope of delivery

FLIR E6 Pro infrared camera
Hard-shell transport case
Battery (in camera)
Power supply (with plugs for EU, GB, USA and Australia)
FLIR thermal studio starter
Printed documents
