Name: Fluke FLUKE-PVA-1500HE2 PV tester
Brand: Fluke
SKU: 3161933
Availability: BackOrder

A Fluke cable locator set with a black transport case, a handheld device, accessories including cables, probes, and a carry bag.

Datasheet (PDF)

EAN:

Part number:

Item no:

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 23,415.00 / piece)

€ 23,415.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Voltage range 20 - 1500 V/DC
Max. Current 30 A/DC
Accuracy of voltage current measurement 0.5 %
I-U characteristic points: 100 or 500 can be selected
Operating temperature: 0 °C to +45 °C
Max. I-U-sweeps 400/h
Max. Measurable performance 3.5 mw/h

Product type: PV tester

Reading type: Analysis

: Manufacturer's standards (no certificate)

Illuminance reading accuracy: 1.7 %

Reading category: CAT III 1500 V

Interfaces: Radio

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3161933 Fluke FLUKE-PVA-1500HE2 PV tester

Information

Test Summary Report 3161933 Fluke FLUKE-PVA-1500HE2 PV tester

Conformity certificate

Conformity certificate 3161933 Fluke FLUKE-PVA-1500HE2 PV tester

Security datasheet

Security datasheet 3161933 Fluke FLUKE-PVA-1500HE2 PV tester

Description

The Fluke-PVA-1500HE2 Solmetric with highly developed I-U characteristic curve tracking provides precise analysis and optimization of photovoltaic systems (PV). With the PVA-1500HE2, professional users of solar energy can accurately measure the performance of PV modules, strings and plants up to a total of 30 A in real time, including highly efficient strands, even those that exceed a module efficiency of 19%. With the PVA-1500HE2 users can quickly and effectively detect problems such as shading, disproportion, deterioration and other performance deviations. Thanks to its user-friendly interface and ergonomic design the device can be used easily, even in difficult environments. Characteristic tracing features comprehensive data analysis and feedback capabilities, enabling technicians to make informed decisions to maximize the performance and reliability of solar power systems. Built for durability and reliability, the Solmetric PVA-1500HE2 is the ideal tool for professional users of solar energy who strive to optimize the performance and longevity of PV systems.

This text is machine translated.

Features

Measures and displays I-V curves up to 1500 V and 30A, even on highly efficient modules
Integrated PV performance modeling and advanced wireless radiation, temperature and tilt detection
Unprecedented throughput with sweep-to-sweep delays of just 9 seconds
Saves time through automated data analysis and reporting and streamlines the process of capturing and interpreting measurement results

Scope of delivery

FLK-SOLMETRIC 1500V HIGH EFFICIENCY PV ANALYZER
1 Transport case (hard case)
1 I-V unit Measuring head
1 I-V-unit Softcase for HE
1 open-end wrench set (MC4 key)
1 test lead set banana plug for MC4
1 test lead set banana plugs to dolphin clamp
1 Quick reference card
1 PVA charging plug with two connectors
2 PVA USB-charging cable
1 SolSensor 300 measuring unit
1 Module frame terminal
1 pack with 2 K-type thermocouple temperature sensors
1 pack of 50 adhesive disks for fixing thermocouples
1 Solensor Lanyard-Tool
1 spray bottle with distilled water
1 micro fiber cleaning cloth

Description

Features

Measures and displays I-V curves up to 1500 V and 30A, even on highly efficient modules
Integrated PV performance modeling and advanced wireless radiation, temperature and tilt detection
Unprecedented throughput with sweep-to-sweep delays of just 9 seconds
Saves time through automated data analysis and reporting and streamlines the process of capturing and interpreting measurement results
